Map editor
Navigation: Configuration → Map editor — route /map-editor, or the
Map editor link on the edit page of a game map.
Spawn areas and gates are coordinates on a terrain. Editing them in the generic form means typing numbers; the map editor lets you place them on the rendered terrain of the map instead.
Selecting a map
The drop-down at the top selects the map to edit. Next to it are the buttons to export and import a map, see below.
What you can create
| Object | Purpose |
|---|---|
| Monster spawn area | Where a monster (or NPC) spawns, how many of them, and in which rectangle they may appear |
| Enter gate | The area a player arrives in when entering the map through a gate |
| Exit gate | The area which sends a player to another map, and its target |
Click one of the create buttons, then draw the object on the map. Confirm it with the ✔ button or discard it with ✘.
Editing existing objects
Click an object on the map to focus it. The properties of the focused object are shown next to the map, so you can adjust the details — the monster and its quantity for a spawn area, the target gate and the direction for an exit gate.
With an object focused you can also:
- Duplicate it, which is the quickest way to add a second, similar spawn area
- Remove it
Undo reverts your last action; it works for the whole editing session, until you save.
Saving
Nothing is written to the database until you press Save. Leaving the page without saving discards the changes.
Like the other configuration changes, a modified map takes effect after the game servers reload their configuration — use Reload configuration and restart all game servers on the Servers page.
Export and import
Export map downloads the map's editable content as a JSON file, Import map reads such a file back in.
This is how you
- back up a map before larger changes,
- move a map layout from a test server to your live server,
- share a custom map with someone else.
Import replaces the objects of the currently selected map, so export first if you want to be able to go back.
